Auto cutting machineAre you here:HomeProducts > Machine > Auto cutting machine

Category: Auto cutting machine
Brand: Jialuolaser
Model: ACT-II-F
Views: 983
Scope:

Share
Contact Us:+86-755-8178-7866
Product Details
ACT II computer automatic cutting machine

Machinery size

1800×850×1550mm

Machinery weight

150kg

Supply power

220V AC 1PH 50Hz 1KW

Air-pressure pump

≥6kg/cm² pressure, diameter 10mm of gas tube

 Software operation platform

Microsoft Windows 2000﹑XP﹑Vista

Support language

Chinese﹑English

 Support input files format

DXF﹑AI

Support output files format

DXF、JLD

Blades highness scope

23.8mm

Blades thickness scope

0.71mm

Cutting shape(att.)

 Lipping 23.8mm(Att), straight line

Notching(att.)

Width 6mm high 18.8mm

Min gap width of the perforating

1mm

Att: It would be as per clients require to make the size

1.Automatic production,no need man operation,esay to use it

2.There are 2 bobbin crease rules,you can change the material speedily


3.Save the time,power and materials,also can make 4 bobbin crease rules

4.Provided 2 cutting position , it can cut and bridge,the height of bridges can be easy changed, and aslo expanding cutting position and custom-made dies by the customer
